Renewable Energy Manufacturing
Precision-machined components for wind, solar, energy storage, and hydrogen systems. From pitch bearing housings and solar tracker gearbox parts to battery enclosures and bipolar plates — built with the corrosion resistance and dimensional accuracy that outdoor, high-cycle energy hardware demands.
Why Energy Engineers Choose MakerStage
Renewable energy hardware lives outdoors for 20-25 years. We combine the right alloys, surface treatments, and dimensional control so your parts perform through every weather cycle.
Corrosion Engineering
316L stainless, duplex 2205, hot-dip galvanized steel, and marine-grade aluminum 5052/6061 — selected for 20+ year outdoor life
Tight Tolerances
±0.0005" on bearing seats and shaft interfaces; ±0.005" on structural brackets — critical for wind turbine pitch and yaw systems
Rapid Prototyping
Typical 1-3 day turnaround for 3D-printed prototypes; CNC and sheet metal prototypes typically in 10-15 days — accelerate your design validation cycle
Scale-Ready
Prototype to production (100-10,000 pcs) with rigorous quality control. Full traceability and material certifications per ASTM / ISO standards
Renewable Energy Manufacturing Capabilities
Purpose-built manufacturing processes for energy hardware — from CNC-machined drivetrain components to laser-cut mounting structures and precision sheet metal enclosures.
Precision CNC Machining
3-Axis & 5-Axis Capabilities
Energy-Grade Specifications
±0.005" standard, as tight as ±0.0005"
Ra 3.2 µm standard, Ra 0.8 µm achievable
24" × 16" × 12"
Typically 10-15 days
Energy-Grade Materials
Energy Applications
- Wind turbine pitch bearing housings
- Yaw drive gear plates and adapters
- Solar tracker slew drive components
- Inverter and converter heat sinks
Sheet Metal & Fabrication
Laser Cut, Formed & Welded
Fabrication Specifications
±0.005" kerf control
±0.010" standard
24 ga – 0.25" (6 mm)
Typically 10-15 days
Sheet Metal Materials
Energy Applications
- Components for IP65/IP67 battery module enclosures
- Solar panel mounting rails and brackets
- Inverter and junction box housings
- Cable tray and bus bar assemblies
Rapid Prototyping & 3D Printing
Accelerate Design Validation
Prototyping Specifications
25 µm (SLA)
±0.1 mm typical
16" × 16" × 20"
Typically 1-3 days
3D Printing Materials
Energy Applications
- Blade root attachment prototypes
- Connector and cable routing fixtures
- Thermal management duct mock-ups
- Sensor housing fit-check models
Surface Treatment & Coatings
Coatings for 20+ Year Design Life
Coating Specifications
Type II/III, 0.0002-0.003"
2-5 mil, TGIC polyester
Hot-dip zinc per ASTM A153
Citric per ASTM A967
Available Treatments
Energy Applications
- Offshore wind corrosion protection
- Desert solar UV-resistant finishes
- Battery enclosure thermal coatings
- Electrical isolation finishes
Renewable Energy Applications
We manufacture precision components across the full renewable energy value chain — wind, solar, battery storage, and hydrogen fuel cell systems.
Wind Turbine Components
Onshore and offshore wind turbines requiring fatigue-rated, corrosion-resistant drivetrain and structural components
- Pitch bearing housings and adapter plates
- Yaw drive gear rings and pinion shafts
- Main shaft couplings and flanges
- Nacelle structural brackets
Solar Tracker Systems
Single-axis and dual-axis solar trackers requiring precise rotational components with UV and weather resistance
- Slew drive housings and worm gear components
- Torque tube couplings and bearing blocks
- Actuator mounting brackets
- Pier cap adapters and post caps
Battery & Energy Storage
Li-ion, LFP, and flow battery systems requiring sealed enclosures, thermal management, and electrical isolation
- Components for IP65/IP67-rated module enclosures
- Bus bar assemblies — copper and aluminum
- Thermal interface plate machining
- BMS housing and connector brackets
Hydrogen & Fuel Cells
PEM and SOFC fuel cell stacks requiring gas-tight sealing surfaces and chemically inert materials
- PEM bipolar plates — graphite and SS 316L
- End plate assemblies with sealing grooves
- Hydrogen manifold and fitting components
- Reformer heat exchanger parts
Power Electronics & Inverters
Grid-tie inverters, DC-DC converters, and power conditioning units requiring efficient thermal dissipation
- Finned heat sinks — extruded or machined
- IGBT module cold plates
- EMI shield enclosures
- Transformer lamination stack fixtures
Electrical Infrastructure
Medium-voltage collection systems and substation equipment requiring NEMA-rated outdoor enclosures
- Substation bushing clamps and connectors
- Cable tray sections and splice plates
- Grounding bus bars and lug assemblies
- Weatherproof junction box housings
Renewable Energy Manufacturing FAQ
Common questions from energy engineers about our precision manufacturing capabilities for wind, solar, and storage systems.
What materials do you recommend for outdoor renewable energy components?
For structural parts exposed to weather, we typically recommend 316L stainless steel for superior chloride resistance (critical near coastal or offshore sites), hot-dip galvanized carbon steel per ASTM A153 for cost-effective corrosion protection, or aluminum 5052-H32 for lightweight brackets with good saltwater resistance. For high-temperature applications such as inverter heat sinks, aluminum 6061-T6 offers an excellent strength-to-weight ratio with thermal conductivity of ~167 W/m·K. Material selection depends on your specific environmental exposure, mechanical loads, and design life target.
What tolerances can you hold for wind turbine drivetrain components?
For bearing seats and shaft interfaces we can achieve ±0.0005" (±0.013 mm) with surface finishes of Ra 0.8 µm or better — critical for proper bearing preload and fatigue life in pitch and yaw systems. Structural brackets and adapter plates are typically held to ±0.005" (±0.13 mm). Our 5-axis CNC capability allows tight tolerances on complex multi-feature parts like yaw gear rings where concentricity and perpendicularity are critical.
Can you manufacture components for IP65 or IP67 battery enclosures?
Yes. We fabricate enclosure components for battery module and rack builds—housings from stainless 304/316 or aluminum 5052/6061 sheet metal with O-ring gland machining, gasket channels, and sealed cable entry points used in IP65 or IP67 designs. We can also include threaded inserts for EMI gaskets and provide powder-coated or anodized finishes. Typical wall thickness ranges from 1.5 mm to 3 mm depending on structural and thermal requirements.
What surface treatments extend outdoor component life to 20+ years?
For aluminum parts, Type III hard anodize (per MIL-PRF-8625) provides an abrasion-resistant oxide layer of 0.002-0.003". TGIC polyester powder coat (2-5 mil) adds UV resistance designed for up to 10+ year exterior exposure in typical conditions. For steel, hot-dip galvanizing per ASTM A153 provides 50-100 µm zinc coating that sacrificially protects the base metal. Stainless steel parts benefit from citric acid passivation per ASTM A967 to maximize the chromium oxide passive layer. We recommend combining treatments — for example, anodize + powder coat — for extreme environments.
Do you support prototype-to-production scaling for energy hardware?
Absolutely. We handle the full development cycle: 3D-printed concept models typically in 1-3 days, CNC-machined functional prototypes typically in 10-15 days, and production batches of 100-10,000 pieces with rigorous quality control. All production parts include material certifications (mill certs per ASTM/ISO standards), dimensional inspection reports, and full traceability. This lets you validate form, fit, and function before committing to production tooling.
Can you machine hydrogen fuel cell bipolar plates?
Yes. We machine PEM fuel cell bipolar plates from 316L stainless steel or graphite composite blanks. Our 5-axis capability allows us to cut flow-field channels with typical widths of 0.5-1.5 mm and depths of 0.3-1.0 mm with ±0.05 mm precision. We also machine end plates with precision O-ring grooves for stack sealing. Surface finish on sealing faces can achieve Ra 0.4 µm or better for gas-tight assembly.
Power Your Clean Energy Build
Get a quote for wind turbine components, solar tracker parts, battery enclosures, or hydrogen fuel cell plates — with corrosion-resistant alloys and full material documentation.
